Model No.:PZ-1000-14A
The 14 heads multihead weigher,suited to many food and non-food applications. They combine high-speed operation with unparalleled accuracy and reliability,and are pivotal to the improvement of efficiency and consistency on the production line, can be installed as part of an integrated weighing and packing line or interfaced with existing packing equipment.
Technical Data and Specifications
Features and functions
1.Factory settings restore function.
2.Easy clean:hopper remain open,easy for clean and daily maintenance.
3.Counting on granules function.
4.IP Grade:IP65,protection against water and dust.
5.Defects rejecting
6.Gate open angel resettable,depends on materials characteristics.
7.Preset of 99 groups of products data.
8.Drops of materials from weighing heads in turn,preventing from materials jamming.
9.Multichoice of material feeding,connectable to high speed packaging machine and other machine.
10.Modular design of control system for the function expansion of weighing system.
11.Low cost and easy maintenance,repair.
12.Digital weighing module imported originally from Germany(A/D),high precision and stability.Module interchangeable.
13.Operation authorization settable through touch screen,easy for management.
14.Touch screen software upgrading through U disk.
15.Components imported from Japan ensuring high efficiency and stability.
The 14 heads multihead weigher,suited to many food and non-food applications. They combine high-speed operation with unparalleled accuracy and reliability,and are pivotal to the improvement of efficiency and consistency on the production line, can be installed as part of an integrated weighing and packing line or interfaced with existing packing equipment.
Technical Data and Specifications
| Product Name | Computer-control Multihead Packaging Weigher |
| Product Model | PZ-1000-14A |
| Weighing heads | 14 |
| Weighing Accuracy | 0.3g~1g |
| Speed(per min) | 45-60packages(25~30packages if with package machine together) |
| Single Head Range | 500g |
| Weighing Range | 20-1000g |
| Volume/ Single head | 1.8L |
| Volume | Max 2.8L |
| Head Open Mechanism | Cylinder drive |
| Material | thread type anti sticking SUS304 stainless steel |
| Monitor/Display and Language | 7 inch screen ,English or Chinese |
| Measurement(mm) | 1250×1150×1115 |
| Weight | ≈500kg |
| Power Supply | 220V±10%,AC Single Phase,frequency: 50HZ,1.1KW 8.2A |
| Pre-Recipe function | 10 recipe ,functioned with automatic back to zero |
| Packaging machine correlation function | workable |
| Weighing System Protection Grade | IP69K |
| Assembly Protection Grade | IP67 |
Features and functions
1.Factory settings restore function.
2.Easy clean:hopper remain open,easy for clean and daily maintenance.
3.Counting on granules function.
4.IP Grade:IP65,protection against water and dust.
5.Defects rejecting
6.Gate open angel resettable,depends on materials characteristics.
7.Preset of 99 groups of products data.
8.Drops of materials from weighing heads in turn,preventing from materials jamming.
9.Multichoice of material feeding,connectable to high speed packaging machine and other machine.
10.Modular design of control system for the function expansion of weighing system.
11.Low cost and easy maintenance,repair.
12.Digital weighing module imported originally from Germany(A/D),high precision and stability.Module interchangeable.
13.Operation authorization settable through touch screen,easy for management.
14.Touch screen software upgrading through U disk.
15.Components imported from Japan ensuring high efficiency and stability.
